| Imagine
a new kind of amplifier that combines the best of both the solid
state and tube technologies. An energy efficient "green"
design requiring no tube biasing or regular maintenance. An amplifier
having the smooth and organic sound that only tubes can provide
combined with the dynamics and slam of the solid state. Such an
amplifier now exists! Critics are already using words like "Groundbreaking"
and "Revolutionary" to describe our new tube/Class D hybrid
amplifiers.
These new amplifiers are much more than simply a tube circuit placed
in front of a class D output section. Our proprietary tubeD™
circuit topology actually integrates the tube section into the amplifier
yielding the smooth natural sound that only a tube amp can provide.
With almost uncanny accuracy the Dragon and Hydra amps deliver stunning
dynamics and transparency without any of the edgy, etched or grainy
sound that often accompanies solid state designs. A low power standby
mode allows critical amplifier sections to remain continuously powered
on (if desired) and a slow start feature allows the tubes to warm
up gradually to eliminate turn-on noise and greatly extend tube
life. Three massive linear power supplies are used to power the
amplifier circuitry and ultra-high quality parts are used exclusively
throughout the design. Combined with a stunning appearance, you
can be certain that you are investing in an amplifier that truly
represents the very leading edge of audio technology.
Download product literature here
Awards and Reviews:

Hydra: The Absolute Sound (click
here)
DragoN: The Absolute Sound (click
here)
-
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
General Features:
[back to top]
- NCore Hypex modules in DragoN
- Massive linear power supplies
- Balanced (XLR) and single ended (RCA) inputs
-
Heavy-duty gold plated binding posts
-
Two 12AU7 tube complement
-
Short circuit protection
-
Standby circuitry for solid state components
-
Slow start circuit for extended tube life
-
Machined aluminum
faceplate
- Heavy (2 ounce) copper circuit board
- All precision components
- Fully tested, burned in, and auditioned
- 3 year limited warranty (6 months on tubes)
-
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Specifications:
[back to top]
- Output power Dragon: 300/500 WPC 8/4 Ohms
-
Output power Hydra: 100/200 WPC 8/4 Ohms
-
Input impedance: 200K Ohms
- Frequency response: 10Hz - 20KHz ± 1dB
- THD: <0.1% typ., <1.0% at rated power
- Input sensitivity: 1.0V RMS
- Dimensions: 18" W x 15" D x 5.5" H
- Weight: DragoN 38 lbs Hydra 34 lbs
- Power requirements: 120/240V - 50/60Hz
Specifications
subject to change without notice
|
